Signature Series Evolution - Air/Water Reel - Low Pressure - 50' x 1/2" ID hose

USD $535.00

44-2140-011
Balcrank Corporation
Made In The USA
Click to see additional Options / Models / Accessories Available
Options Accessories



Click to view California Proposition 65 warning



Lightweight but extremely rugged: steel pedestal and arm, and dual ball-bearings. The Evolution combines design, performance, and reliability with the right features and benefits for today's customers. All Evolution series reels have a narrow and lightweight design; includes hose, hose stop, and a 2.5" connecting hose. - Superb corrosion resistance - Superior structural design and stability - Fully ported shaft and pressure balanced swivel - High-quality, long-life power spring - Spool mounted on dual ball-bearings - Rectangular hose guide outlet with rollers - Multi-Positioning outlet arm



Features

  • Air and Water Low Pressure 300 psi (21 bar) for delivery of air, water, and Anti-freeze.
  • Eight-position latching mechanism.
  • Fluid compatibility for multiple applications.
  • Easy maintenance and service.
  • Easy on-site tension adjustment.
  • Easy installation mounting and accessories.
  • Fluid inlet - 1/2" NPT (F) swivel.
  • Fluid outlet - 1/2" NPT (F) swivel.
  • Outlet thread - 1/2" NPT (M).
  • Wetted materials - Nickle plated steel and Buna-N™.



Technical

Weight approx. 50 lbs
Power supply Air V/Hz/A
Dimensions (L x W x H) 18 x 6-1/2 x 20 inch



Options

44-2140-008 Evolution Air/Water Reel - 50' x 3/8" $499.00 Cart Add to cart
44-2230-002 Mounting Channel - 1 Reel $91.00 Cart Add to cart
44-2230-002 Mounting Channel I-Beam Bracket Kit $91.00 Cart Add to cart
44-2230-003 Mounting Channel - 1 Reel $95.00 Cart Add to cart
44-2230-004 Mounting Channel - 2 Reels $120.00 Cart Add to cart
44-2230-005 Mounting Channel - 3 Reels $152.00 Cart Add to cart
44-2230-007 Mounting Channel - 5 Reels $216.00 Cart Add to cart
44-2230-010 Hose Stop - 1/2" ID Hose $26.00 Cart Add to cart
44-2230-014 Mounting Channel Plate $48.00 Cart Add to cart
44-8141-050 Hose Assembly 50' x 1/2" Low Pressure $206.00 Cart Add to cart



Accessories

44-3230-015 In-Line Hand Operated Valve for Oil - 1/2" - 7250 PSI $68.00 Cart Add to cart
44-3230-016 In-Line Hand Operated Valve for Oil - 3/4" - 5800 PSI $133.00 Cart Add to cart
44-3230-017 In-Line Hand Operated Valve for Oil - 1" - 5075 PSI $207.00 Cart Add to cart
44-3230-023 In-Line Hand Operated Valve for Oil - 3/8" - 7250 PSI $48.00 Cart Add to cart
