High Flow Control Handle is designed for service where larger volume deliveries are required.

Applications:

• Ideal for high volume dispense and bulk transfer.
• Lube and service trucks.



Features

• High volume flexible outlet with non-drip tip.
• Outlet with 3/4” NPT(F) connection thread and bonded seal to assure a leak free operation.
• Used where metered fast delivery is required.
• Heavy duty rigid design.
• Max pressure: 1,450 psi (100 bar).
• Swivel inlet: 3/4” NPT(F).
• Compatible fluids: Lubricants (up to SAE 140), Diesel, Oil, ATF, anti-freeze (Glycol), Gear Oil Maximum viscosity SAE 140.
• Wetted materials: Liquid Crystal Polymer (LCP), Aluminum, Buna-N™, Zinc Plated Steel, Stainless Steel.



Technical

Dimensions (L x W x H)	22.83 x 3.12	inch
Power supply	Air	V/Hz/A
Weight approx.	3	lbs
