Digital in-line meter designed specifically to dispense motor oils, automatic transmission fluid, antifreeze (Glycol) and antifreeze/water solution. When not in use for 30 seconds, the meter enters “sleep mode”, which prolongs battery life. When in sleep mode, the meter is turned on by a simple press of the ON/RESET button or if the meter detects fluid flow. The electronic register module can be programmed to dispense in pints, quarts, liters, or gallons and will totalize in liters or gallons. A calibration factor and unit of measure are programmed during factory test. A 5-digit liquid crystal display, accurate to the third decimal place, shows the exact amount of fluid dispensed.



Features

• units of measure include liters, gallons, qts and pints
• 1/2" NPT (F) inlet/outlet threads
• accuracy: +/- 0.5% (after field calibration)
• max pressure : 1450 psi



Technical

Dimensions (L x W x H)	3.66 x 2 x 3.66	inch
Power supply	2 x 1.5v AAA batteries	V/Hz/A
Weight approx.	1.2	lbs
