High Flow Control Handle is designed for service where larger volume deliveries are required. Used where metered fast delivery is required Ideal for bulk fill, transfer, and high flow dispense: Mining and construction vehicles Lube and service trucks Manufacturing plants Compatible fluids: Lubricants (up to SAE 140), Diesel, Oil, ATF, anti-freeze (Glycol), Gear Oil Maximum viscosity SAE 140 Wetted materials: Liquid Crystal Polymer (LCP), Aluminum, Buna-N™, Zinc Plated Steel, Stainless Steel



Features

• High volume rigid outlet with non-drip tip.
• Outlet with 3/4” NPT(F) connection thread and bonded seal to assure a leak free operation.
• Heavy duty rigid design
• Max Flow: 18.6 Gal/min. (70 L/min.)
• Max pressure 1,450 psi (100 bar)
• Swivel inlet 3/4” & 1″ NPT(F)



Technical

Power supply	air max. pressure 1450psi	V/Hz/A
Weight approx.	5	lbs
Dimensions (L x W x H)	20 x 3.2 x 3.2	inch
