These packages are suitable for storage and dispensing of DEF, diesel and biofuels, motor oil and ATF or similar products up to SAE 90. All tank packages are double-wall with 4x 2” bung openings. Balcrank offers UL 2258* rated tanks from 165 to 400 gallons in double wall options. Tank-less packages contain the same equipment excluding the tank, for customers who have local access to tanks. *As with all tanks, be sure to follow local and state guidelines for tank placement and installation. Some cities and counties have not approved the UL 2258 certification, as it is different that the familiar UL142 that pertains to steel tanks, so be sure to check with your local Fire Marshal and/or city and county regulations before ordering. Package Includes: • Lightweight Doublewall Tank 275 Gal • Choice of: Lynx 3:1, Lynx 5:1 HD or Panther 3:1 Pump 30' or 50′ x 1/2″ ID Classic or Evolution Hose Reel • DR Handle w/Flex Ext. & Auto Tip • F/R auto drain 1/4” NPT(F) • 2.5' reel inlet hose • 5' air connecting hose • Air quick connect coupler & nipple • Sight gauge • Vented fill cap • Pump & reel bracket



Features

• Inner tank made of blow-molded, high-density, seamless polyethylene that is leak-proof and will never corrode
• Outer tank is made of weld-free galvanized steel and roll seamed with an oil and fire-resistant seal
• Outer tank holds 110 percent of inner tank for maximum protection
• Extremely light, up to 50 percent lighter than conventional steel tanks
• Can be used for DEF, diesel and bio fuels, motor oil and ATF
• Compact, economical design (8 sq. ft. for 1000L)
• Wide handles on each end allow you to transport and handle with ease
• UL 2258 certified*
• 4 x 2” bung openings



Technical

Weight approx.	353	lbs
Dimensions (L x W x H)	3′ 6.875″l x 2′ 3.25″w x 5′ 1″ h	inch
Power supply	air	V/Hz/A
