10,000 lb. capacity electric/hydraulic inground lift with 8.5 in. chrome pistons, wide drive-through, 3-stage arms and double telescoping screw pads.



Features

• 10,000 lb. lift capacity.
• 3-stage front and 3-stage rear arms provide access to the lift points of a wide range of cars and trucks, maximizing revenue potential.
• 8.5 in. diameter chrome pistons provide greater stability under load.
• Chrome non-breathing ram style cylinder provides for longer lift life.
• Enhanced raised wiper at top and bottom of bearing provides better grease retention and minimizes contaminates from entering into bearings.
• Long bearing contact provides increased stability.
• Mechanical lock engages every 3 in. allowing ergonomic working height for technicians to increase productivity and minimize fatigue.
• Stainless steel air lock release cylinder promotes longer working life with its corrosion resistant design.
• Fully-contained and sealed recycled polymer cassette tub eliminates risk of hydraulic fluid seeping into the ground.
• Premium double telescoping screw pads adjust to multiple heights minimizing the need for adapters.
• 87_ drive-thru accommodates wider vehicles, minimizes tire damage and provides for easy drive-on.



Technical

Load carrying capacity	10,000	lbs
Lifting height	75	inch
Lifting/lowering time approx.	40	s
Weight approx.	2,950	lbs
Color	Any
Track width	110	inch
Power supply	208-230	V/Hz/A



Options

67-EV1020-QC	10,000 lb. Inground Lift with Quick Cycle Technology	$12,022.00	Add to cart
67-3PH208	Power Unit Upgrade to 208V 3PH	$770.00	Add to cart
67-3PH230	Power Unit Upgrade to 230V 3PH	$770.00	Add to cart
67-3PH460	Power Unit Upgrade to 460V 3PH	$770.00	Add to cart



Accessories

67-15060	Floor Mounted Power Unit Stand (For use with EV1020 and EV1220 model lifts)	$239.00	Add to cart
67-15060	Floor-Mounted Power Supply (For inground lift models)	$239.00	Add to cart
67-SD100	Automatic Liquid Removal System	$831.00	Add to cart
